--==[ Path Profile Analysis ]==--

Transmitter site: Tx

Site location: 43.6590, -79.3789

Ground elevation: 328.08 feet AMSL

Antenna height: 6.40 feet AGL / 334.48 feet AMSL

Distance to Rx: 0.04 miles

Azimuth to Rx: 268.01 degrees grid

Downtilt angle to Rx: +0.2288 degrees

Receiver site: Rx

Site location: 43.6590, -79.3797

Ground elevation: 331.36 feet AMSL

Antenna height: 4.00 feet AGL / 335.36 feet AMSL

Distance to Tx: 0.04 miles

Azimuth to Tx: 88.01 degrees grid

Downtilt angle to Tx: -0.2294 degrees

Propagation model: Line of sight

Model sub-type: Rural / Optimistic

Earth's Dielectric Constant: 15.000

Earth's Conductivity: 0.005 Siemens/meter

Atmospheric Bending Constant (N-units): 301.000 ppm

Frequency: 2400.000 MHz

Radio Climate: 5 (Continental Temperate)

Polarisation: 1 (Vertical)

Fraction of Situations: 50.0%

Fraction of Time: 50.0%

Summary for the link between Tx and Rx:

Free space path loss: 76.61 dB

Computed path loss: 0.00 dB

Model error! Computed loss of 0.0dB is greater than free space loss of 76.6dB. Check your inuts for model 2
